Creating stunning silhouettes, ECORAY features an innovative reflector technology system allowing a soft projection of light. With colour temperature and dimming options, the luminaire can suit modern and traditional sites.
11.9W - 52.3W
1,430 - 7,080 Luminaire Lumens
Efficacy up to 138.0 lm/W
2700K, 3000K, 4000K, CRI>70
IP66, IK08
Lifetime >100,000hr, L90
Constant Light Output
Part Night Dimming
The ECORAYS luminaire shall be manufactured from high-pressure die-cast aluminium and powder coated with a graphite grey marine grade finish. It shall have Zhaga D4i Certification, with a power output of 11.9 - 138.0W, with an efficacy of up to 138lm/W. It shall deliver up to 5,160 luminaire lumens. The ECORAYS shall utilise reflector-based optics to create a comfortable low glare illumination with distributions to suit pathways, roadways, and open areas such as carparks. It shall have a fully programmable DALI driver. The luminaire shall come in 2700K, 3000k and 4000K and be IK09 and IP66 rated as well as come with catenary, cradle mounted, post top and side entry options available.
Street Lighting
Parks and Plazas
Urban Environment
Public Realm
Ensuring a consistent light output throughout the lifetime of your luminaires, this option optimises power consumption, reduces energy costs and increases luminaire longevity.
This option allows the light to be present only when needed through scheduled intervals to save energy and meet your exact needs.
Available in 2700K, 3000K and 4000K, this luminaire will help you achieve the perfect visual comfort throughout projects boasting a sense of human centricity throughout.
