RAY is a ceiling recessed fitting that comes in stainless steel with an LED light source. There is a range of sizes and beam angles in the family.
4.0W - 20.0W
375 - 2,250 Luminaire Lumens
Efficacy up to 144.0 lm/W
3000K, 4000K, CRI>70
IP67, IP68, IK07, IK08, IK09
Lifetime > 60,000hr, L80
Colour Temperature Options
RGBW Opportunities
The RAY range shall be manufactured from die-cast aluminium with 316L stainless steel trim. It shall have power outputs ranging from 4 - 12W, with an efficacy of up to 130 lm/W. It shall deliver 450 - 1,150 luminaire lumens. The RAY is available with a range of different beam angles and sizes from 25 - 180mm to suit a wide variety of projects. Available in 3000K, 4000K or RGBW, the luminaire shall be IK07 and IP67 rated.
Retail Parks
Atria and Foyers
Paths & Walkways
Hotels & Leisure
